Schilke Trumpet Mouthpiece

Model

mm

Inches

Throat

Description

5A4a

15.84

0.624

27

Small cup diameter with tighter "A" backbore and semi-flat rim offers comfort and resistance in the upper register.

5A4

15.84

0.624

26

Same as the 5A4a but with a standard "c" backbore and larger throat, which offers less resistance.

6A4a

15.99

0.63

27

A shallow "A" cup with cushion #4 rim for extreme high register work.

7B4

16.08

0.633

26

Excellent for the player with thin lips. A #4 rim provides good endurance with a brilliant tone.

8A4

16.25

0.64

26

The slightly funnel-shaped cup at the entrance to the throat provides a good tone and the #4 semi-flat rim gives superior endurance.

8E2

16.15

0.636

26

The deep funnel-shaped cup provides a smooth tone and is very flexible in all registers. Recommended for cornet players.

9

16.33

0.643

26

Standard characteristics allow for a full penetrating tone quality.

9C4

16.36

0.644

26

Like the #9, however the #4 semi-flat rim provides excellent endurance.

10A4a

16.43

0.647

27

The combination of the shallow "A" cup, semi-flat #4 rim and tight "a" backbore assists with upper register work.

10A4

16.43

0.647

27

Same as the 10A4a but with a standard "c" backbore, which offers less resistance.

10B4

16.43

0.647

26

A medium-small funnel-shaped "B" cup offers both a quality sound and support in the register

11A

16.51

0.65

26

This rim size and contour is similar to the #11 but with a shallower "A" cup.

11AX

16.51

0.65

27

This model was developed for the Schilke piccolo trumpets. The "x" backbore improves the ease of playing and opens up the sound on the piccolo. Also available in a trumpet shank.

11C2

16.51

0.65

26

Similar to the #11 featuring a slightly rounded #2 rim countour.

11

16.53

0.653

26

A superior mouthpiece with standard characteristics for a free blowing mouthpiece.

11D4

16.58

0.653

26

Slightly deeper than the #11 with a #4 semi-flat rim, which provides a definate cushion feel for endurance.

11E

16.58

0.653

26

The large funnel-shaped cup encourages a big round tone, ideal for cornet.

12A4a

16.71

0.658

27

Similar to the 12B4 but with a shallow "A" cup, tight "a" backbore which adds both endurance and range.

12A4

16.71

0.658

27

This mouthpiece is the same as a 12A4a but with a standard "c" backbore.

12B4

16.71

0.658

26

This medium-small conical "B" cup provides a full tone and the #4 semi-flat rim allows for more endurance.

12

16.69

0.657

26

A traditional medium size mouthpiece that includes a #3 standard rim and "c" backbore allows the player a full spectrum of sound.

13A4a

16.76

0.66

27

The shallow "A" cup, semi-flat #4 rim and tight "a" backbore creates an ideal lead mouthpiece.

13A4

16.76

0.66

27

Same as the 13A4a but with the standard "c" backbore which allows a freer blowing feel.

13B

16.77

0.66

26

This mouthpiece has a "B" cup that is slightly deeper than the 13A4 and also offers a narrower, round rim.

13

16.89

0.665

26

Ideal choice for a student or developing player with standard #3 rim contour. Rounder rim provides increased flexibility and quick response. "C" cup offers volume for tone.

13C4

16.89

0.665

26

A somewhat sharp inner-edge combined with a funnel-shaped "C" cup offers a clear tone. The #4 semi-flat rim adds increased endurance.

13D4

16.89

0.665

27

Best option for a player looking for a thick, rich, weighted sound. Medium large "D" cup offers a tone that is colorful with depth. #4 semi-flat rim affords comfort with sharper bite for superior articulation clarity. Diameter ideal for all players from student to professional.

14A4a

17.09

0.673

27

One of our most popular mouthpieces, the 14A4a offers a shallow "A" cup, semi-flat #4 rim and tight "a" backbore allows a player a strong upper register without sacrificing tonal production.

14A4

17.09

0.673

27

Same as the 14A4a but with a standard "c" backbore which offers a more "open" feel.

14A4x

17.09

0.673

27

Based on the popular 14A4a, this mouthpiece creates a very open blowing feel with the large ?x? backbore. This backbore improves the ease of playing and opens up the sound of our piccolo trumpet. Also ideal for Eb soprano cornet.

14B

17.02

0.67

26

Similar to the #14 but with a "B" (medium-small) cup size.

14C2

17.02

0.67

26

This "C" cup and #2 semi-rounded rim produces a rather large tone and good center.

14

17.02

0.67

26

With a standard rim, cup and backbore, the 14 is an excellent choice for all around playing.

14C4

17.09

0.673

26

Offering the same rim contour and diameter as the 14A4a, with the standard "C" cup and backbore for a full, rich tone.

15A4a

17.14

0.675

27

A larger diameter mouthpiece with a shallow "A" cup and tight "a" backbore for upper register playing. #4 semi-flat rim offers comfort in upper register.

15A4

17.14

0.675

27

Same as the 15A4a but with a larger "c" backbore for an open feel.

15B

17.12

0.674

26

With the same diameter as the #15, this mouthpiece includes "B" style cup which produces a more brilliant sound than the standard #15 mouthpiece.

15

17.12

0.674

26

An excellent all-around mouthpiece which offers a free blowing, clear sound.

15C4

17.14

0.675

26

This mouthpiece is similar to the #15 but with the #4 semi-flat rim for increased endurance.

16B4

17.2

0.677

26

Same as the #16C4 except the shallower, medium-small "B" cup offers more resistance, providing a brighter quality of sound. The 16B4 is an excellent choice for Eb trumpet when a player requires a bigger rim diameter.

16C4

17.2

0.677

26

Similar to the 16 in dimensions, this mouthpiece offers our #4 semi-flat rim for a more traditional feel and increased endurance.

16

17.2

0.677

26

With all the standard Schilke charactistics, this medium-large diameter mouthpiece produces a full, free blowing quality.

16C2

17.2

0.677

26

This model offers the same options as the 16, but instead offers a #2 rim for increased flexibility.

17B4

17.33

0.682

26

Well suited for the player looking for a shallower cup in a larger diameter. Medium-small "B" cup offers more brilliance for projection with #4 semi-flat rim for comfort.

17

17.33

0.682

26

A compromise of all the medium characteristics, this mouthpiece is an excellent medium to large diameter mouthpiece.

17D4

17.33

0.682

26

This mouthpiece includes a deeper "D" cup and #4 semi-flat rim for improved endurance.

17D4d

17.33

0.682

26

A larger blowing mouthpiece than the 17D4 because of the increase "d" backbore.

18B4

17.52

0.69

26

Ideal for a classical player looking for a commercial sound, the medium shallow cup and semi-flat rim provide resistance and comfort for upper register playing. Cup shape offers some sparkle in the sound with enough volume for tone.

18

17.52

0.69

26

The high point being nearer to the center makes this mouthpiece feel smaller than it is. The standard characteristics produce a rich, brilliant tone

18C3d

17.52

0.69

26

Similar in dimension to the 18 but with a larger "d" backbore producing a large, teutonic tone.

19

17.65

0.695

26

The "C" cup, #3 rim and standard "c" backbore are similar to the #20 but with a slightly smaller diameter

20

17.78

0.7

26

This large diameter is for the robust embouchure. Original mouthpiece of choice for Renold O. Schilke.

20D2d

17.73

0.698

26

Similar to the #20 in diameter but includes a larger "D" style cup, #2 semi-round rim and larger "d" backbore.

22

18.03

0.71

26

Similar to the #20 but with a larger inside dimeter.

24

18.29

0.72

26

Our largest cup diameter offered. This mouthpiece provides a huge volume of sound.
